Everything you need to know about single and three-phase power

Single-phase and three-phase power distribution systems are suited to a variety of applications but the systems are quite different. Here is a look at the two types of electrical systems

What is a ‘phase’ in power?

Electricity consists of various phases which refers to the current or voltage within a wire or neutral cable. The phase is the actual distribution of the load, with one-phase (two wires) being a lower load and three-phase (three or four wires) a higher power.

What is Alternating Current (AC) power?

Alternating current (AC) is a form of electricity where the flow of current is constantly changing (or alternating). AC power is used to bring electricity to residential, commercial and industrial areas in the form of single-phase or three-phase loads. Single-phase, which is a lower load, is generally sufficient for residential areas while three-phase, the higher load, will be used for commercial or industrial applications.

Single-phase power explained

This is the distribution of AC power from a three-phase source, using single phase plus Neutral, which is used commonly in residential areas for applications such as lighting and heating. this configuration is also used extensively in computer applications.

Benefits of single-phase power

There are so many benefits to single-phase power including:

  • It is the most used AC power supply for up to 20 kilowatts
  • The design of single-phase is less complex
  • Because the design is less complex, it’s also less costly
  • Single-phase has a range of applications
  • It is able to supply sufficient power for homes and non-industrial businesses
  • It provides sufficient power to run motors
  • it provides efficient power for use by computer-based equipment.

Three-phase power explained

Three-phase power is a polyphase system of alternating current electrical power generation, transmission and distribution. Three-phase power is the most common method used to transfer power on electrical grids around the world, and it is also used for powering heavier loads.

The three-phase system consists of four wires (including a neutral) and three conductors. The supply of a three-phase system is constant and can be set up in a star or delta connection – with DELTA – 3 wire – is used for long-distance communication.

Benefits of three-phase power

The biggest benefit of three-phase power systems is the ability to run higher power loads.

What are the main differences between single-phase and three-phase power?

While both power systems use AC power, the biggest difference between single-phase and three-phase power is the delivery thereof. A single-phase system uses simpler cable distribution and protection circuits for smaller loads, a three-phase system requires greater protection and larger cable carrying capacity to accommodate higher loads.

Determining whether a single-phase or three-phase system is needed depends on the application. However, whether you go with single-phase or three-phase, you will be ensured of reliable power distribution.
